Giant Industrial Ceiling Fan - 4.3 Meter Diameter, Industrial Air circulation
An air circulation solution for large spaces, warehouses, halls, logistics centers, agriculture, barns, and cowsheds. This is a particularly strong giant fan with a direct drive motor, available in three/single phase options.
Ask Us About This Product

Giant Industrial Ceiling Fan - 4.3 Meter Diameter, Industrial Air circulation
This is a robust giant ceiling fan with a direct drive motor, providing an efficient air circulation solution for large spaces. Perfect for warehouses, halls, logistics centers, agriculture, barns, and cowsheds. It's available in both three-phase and single-phase versions. This fan not only provides efficient cooling but also reduces energy consumption due to its innovative motor design.
Main Features
- Advanced motor design: Equipped with an external motor with a high-tech heat dispersion system to maintain a low engine temperature. The motor body is patent-protected to prevent dust from entering its internal components. The external positioning of the motor reduces noise level.
- Aerodynamic blades: Blades are made of an aerodynamic polymer material, the same material used for helicopter blades, making them lightweight and highly durable. Their aerodynamic design reduces turbulence and evenly distributes airflow in the space.
- Easy and safe installation: The fan comes with a double hanging hook, reinforced and universal, which helps to automatically adjust the hanging angle.
- High safety level: The motor, fan parts, and installation components all have a high safety level. It comes with high-strength connectors and offers protection against overload in the control system.
- Excellent performance: Unidirectional natural wind covers a particularly large area. The gentle, comfortable, and cool wind provides an average temperature drop in the range of 4 to 9 degrees.

Technical Specifications
Power
480W
Airflow
8,500 CFM
Voltage
220-240V
Motor Type
Magnetic
Diameter (meters)
4.3
Noise Intensity (db)
39
Rotation per Minute (rpm)
90
Optimal Operating Area (m²)
250
International Safety Standards
CE, CB
Potential Operating Area (m²)
610
Water and Dust Resistance Standard
IP65
